Laser Receiver Module Laser Sensor Non Modulator Transmitter Module
Rs. 56.00 Rs. 64.00
- Product Code: SEN-LASER
- SKU -
- Availability: In Stock
- Price in reward points: 12
- For Bulk Order
9962060070
Quick support on WhatsApp (+919962060070) only between morning 11am-4pm, no call will be answered
| -Features boost circuit | |
| -Signal output indicator | |
| -Effective distance | 0.8m (typ), 1.5m (max) |
| -Power | 2.5V ~ 5.0V |
| -Dimension | 47.7mm * 17.9mm |
| -Mounting holes size | 2.0mm" |
| SPECIFICATIONS: | |
| Operating Voltage (VDC) | 5 |
| Operating Temperature (°C) | -30 to 90 |
| Length (mm) | 25 |
| Width (mm) | 15 |
| Height (mm) | 8 |
| Weight (gm) | 3 |
| Shipment Weight | 0.105 kg |
| Shipment Dimensions | 8 × 5 × 5 cm |
OVERVIEW:
-Working Voltage: 5V DC
-Operating Temperature: -30ºc ~ 85ºc
-Output high level when received the laser signal
-Output low level when not receive laser signal.
-Application: Electronic Circuits
PACKAGE INCLUDES:
1 PCS x Laser Receiver Module Laser Sensor Non Modulator Transmitter Module
//SOURCE CODE TAKEN FROM BELOW LINK
//https://robojax.com/learn/arduino/?vid=robojax-laser-sensor
/*
* Laser Sensor module for Arduino
* Turns ON a buzzer or you can control a motor or servo or any other action,
* Watch the video https://youtu.be/h_y1y6eUvIY
* *
Laser Sensor module for Arduino
Written by Ahmad Shamshiri for Robojax.com
on Feb 02, 2018 at 18:24 in Ajax, Ontario, Canada
* Permission granted to share this code given that this
* note is kept with the code.
* Disclaimer: this code is "AS IS" and for educational purpose only.
* This code is "AS IS" without warranty or liability. Free to be used as long as you keep this note intact.*
* This code has been download from Robojax.com
This program is free software: you can redistribute it and/or modify
it under the terms of the GNU General Public License as published by
the Free Software Foundation, either version 3 of the License, or
(at your option) any later version.
This program is distributed in the hope that it will be useful,
but WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
GNU General Public License for more details.
You should have received a copy of the GNU General Public License
along with this program. If not, see <https://www.gnu.org/licenses/>.
/*
/*
*/
// Saser Sensor code for Robojax.com
#define DETECT 2 // pin 2 for sensor
#define ACTION 8 // pin 8 for action to do someting
void setup() {
Serial.begin(9600);
Serial.println("Robojax.com Laser Module Test");
pinMode(DETECT, INPUT);//define detect input pin
pinMode(ACTION, OUTPUT);//define ACTION output pin
// Laser sensor code for Robojax.com
}
void loop() {
// Laser Sensor code for Robojax.com
int detected = digitalRead(DETECT);// read Laser sensor
if( detected == HIGH)
{
digitalWrite(ACTION,HIGH);// set the buzzer ON
Serial.println("Detected!");
}else{
digitalWrite(ACTION,LOW); // Set the buzzer OFF
Serial.println("No laser");
// Laser Sensor code for Robojax.com
}
delay(200);
}
