Ky 035 A3144 Hall Effect Sensor Module
Rs. 27.00 Rs. 33.00
- Product Code: SEN-HALL
- SKU -
- Availability: In Stock
- For Bulk Order
9962060070
Quick support on WhatsApp (+919962060070) only between morning 11am-4pm, no call will be answered
| SPECIFICATIONS: | |
| Color | Black |
| Operating Voltage(VDC) | 5V DC |
| Power Consumption at Rest | 3mA |
| Power Consumption when Switched | 8mA |
| Operating Temperature (°C) | -40 to +90 |
| Shipment Weight | 0.01 kg |
| Shipment Dimensions | 3 × 3 × 1 cm |
OVERVIEW:
-Digital Output Hall-effect sensor.
-Operating voltage: typically 5V.
-Output Current: 25mA.
-It can be used to detect both the poles of a magnet.
-₹ 61.00 (inc GST)
-₹ 51.69 (+18% GST extra)
PACKAGE INCLUDES:
1 PCS x Ky 035 A3144 Hall Effect Sensor Module
int sensorPin = A5; // Declaration of the input pin
// Serial OUT in 9600 baud
//SOURCE CODE TAKEN FROM BELOW LINK
//https://sensorkit.en.joy-it.net/index.php?title=KY-035_Bihor_magnetic_sensor_module
void setup()
{
Serial.begin(9600);
}
// The program measures the current voltage at the sensor,
// calculates the resistance with it and a known resistor
// and outputs it via serial OUT
void loop()
{
// Measuring of the current voltage...
int rawValue = analogRead(sensorPin);
float voltage = rawValue * (5.0/1023) * 1000;
float resitance = 10000 * ( voltage / ( 5000.0 - voltage) );
// ... output via serial interface
Serial.print("Voltage:"); Serial.print(voltage); Serial.print("mV");
Serial.print(", Resistance:"); Serial.print(resitance); Serial.println("Ohm");
Serial.println("---------------------------------------");
delay(500);
}
https://youtu.be/4eqi0G7uY_4
